Fixed Modular Platform

Spider Modular Platforms are designed for speed and ease of set-up, versatile uses, high load capacities and long working spans.By combining different platform segments with the appropriate stirrups, connectors and accessories, virtually any platform configuration can be created.

Built to the durability standard we hold for our own rental fleet, “Spider Mod” is American-made and meets the expectations of the most demanding professional contractors.

×

Specifications

Part NumberItemFunctionCompatible WithExtensionWeightNotes
701037-1Face Roller/Clamp AssemblyFoam Roller, For use on Smooth Surfaces,700903-1 Collapsible Aluminum Work Cage11-18 in. from base of the work cage (279-457 mm)15 lb
(6.8 kg)		Includes Roller Assembly and four clamps
SA-1090Adjustable Wall Roller with Non-Conductive Rubber WheelRubber Wheel, For use on rough surfaces.

Allows operator to adjust the distance between the rollers and the stage, as well as the distance between the rollers		Modular Platform, ST-17, ST-180, ST-19, 701086-1 Steel Work Cage48 in.
(1,219 mm)		10 lb
(4.5 kg)		Set includes: two rollers and four rail clamps
SA-1035Philly Wall RollerPolyurethane caster-style wheel, for use on rough surfaces.

Attaches to any side of basket or work cage		ST-17, ST-180, ST-19, 701086-1 Steel Work Cage5 1/2 in.
(140 mm)		10 lb
(4.5 kg)		Set includes two philly wall rollers with attachment hardware
SA-1036-336″ Wide Face Roller AssemblyFoam Roller, For use on Smooth SurfacesModular Platform, ST-17, ST-180, ST-19, 701086-1 Steel Work Cage5 to 18 in.
(127 to 457 mm)		17 lb
(7.7 kg)		3 Roller Assembly

Set includes two roller brackets, four rail clamps and rollers
SA-1036-448″ Wide Face Roller AssemblyFoam Roller, For use on Smooth SurfacesModular Platform, ST-17, ST-180, ST-19, 701086-1 Steel Work Cage5 to 18 in.
(127 to 457 mm)		21 lb
(9.5 kg)		4 Roller Assembly

Set includes two roller brackets, four rail clamps and rollers
701120-2Fixed Face Roller AssemblyFoam Roller, For use on Smooth SurfacesModular Platform6 -1/2 in.
(152 mm)		5 lb
(2.3 kg)
701036-1Foam Roller AssemblyFoam Roller, For use on Smooth SurfacesModular Platform, ST-17, ST-180, ST-19, 701086-1 Steel Work Cage9-20 in.
(229-508 mm)		12 lb
(5.4 kg)
706067-1Fixed Face RollerFoam Roller, For use on Smooth SurfacesModular Platform5-1/2 in.
(140mm)		3.9 lb
(1.8 kg)
